XE1203F
Name
ADParam_Clk_freq
Bit
s
3-2
Addres
s
01110
Description
CLKOUT frequency (if enabled)
00 -> 1.22 MHz (div ratio :32)
01 -> 2.44 MHz (div ratio :16)
10 -> 4.87 MHz (div ratio :8)
11 -> 9.75 MHz (div ratio :4)
ADParam_Invert
1
01110
Inversion of Rx output data:
0 -> disabled
1 -> enabled
ADParam_RegBW
0
01110
Baseband filter bandwidth calibration:
0 -> enabled
1 -> disabled
ADParam_Regfreq
7
01111
Period of baseband filter bandwidth calibration whilst Rx
enabled:
0 -> only at start-up of the receiver
1 -> 60 seconds (default mode) or 7 seconds (test mode)
ADParam_Regcond
6
01111
Baseband filter bandwidth calibration as a function of selected
bandwidth:
0 -> calibration restarted each time the bandwidth is changed
1 -> no calibration when the bandwidth is changed
ADParam_Xsel
5
01111
Selection of the XOSC load capacitance mode:
0 -> CL+C0 = 15 pF
1 -> CL+C0 = 11 pF, low current mode
ADParam_Resxosc
4-1
01111
Selection of the value of the shunt resistor across ports TKA
and TKB for a third overtone XTAL operation:
0000 -> 3800 k Ω
0010 -> 4.65 k Ω
0100 -> 8.79 k Ω
0110 -> 3.22 k Ω
1000 -> 16.55 k Ω
1010 -> 3.79 k Ω
1100 -> 6.04 k Ω
1110 -> 2.81 k Ω
0001 -> 2.55 k Ω
0011 -> 1.78 k Ω
0101 -> 2.07 k Ω
0111 -> 1.56 k Ω
1001 -> 2.26 k Ω
1011 -> 1.66 k Ω
1101 -> 1.91 k Ω
1111 -> 1.48 k Ω
ADParam_enable_konnex
0
01111
Konnex mode:
0 -> disabled
1 -> enabled
ADParam_Chge_thres
7
10000
Enable programming of the sync and acquisition thresholds:
0 -> threshold are hard-coded and sync-loss counter is 50 bits
1 -> threshold are defined by BParam_Sync_thres and
BParam_Trac_thres
Sync loss counter is variable and defined by
ADParam_Sync_loss
ADParam_Sync_thres
ADParam_disable_data_bidi
r
6:0
7
10000
10001
Barker mode sync acquisition threshold
DATA port bidirectional mode:
0 -> enabled
1 -> disabled: DATA = output, DATAIN = input
ADParam_Trac_thres
? Semtech 2008
6-0
10001
Threshold for tracking Barker mode
www.semtech.com
26
